Product
Manufacturer Material ID –
6AV2123-2DB03-0AX0
Net Weight –
0.46kg
Additional Product Information
Commodity Code –
85371099
Country of Origin –
CN
Export Control Regulations –
AL: N / ECCN: EAR99H
Minimum Order Quantity –
1
RoHs Compliance –
Yes
UNSPSC –
43201503
Technical Specification
Built-in depth –
33 Millimetre
Number of interfaces PROFINET –
1
Recess depth –
33 Millimetre
Screen diagonal –
4.3 inch
Number of HW-interfaces industrial Ethernet –
1
Number of HW-interfaces USB –
1
Number of colours of the display –
65536
Number of pixels, horizontal –
480
Number of pixels, vertical –
272
Number of function buttons, programmable –
4
Useful project memory/user memory –
10000 kiloByte (1000 Byte)
Number of password levels –
50
Number of online languages –
10
Width of the front –
141 Millimetre
Height of the front –
116 Millimetre
Number of HW-interfaces PROFINET –
1
Supply voltage DC –
19.2 Volt
